Distinctive perforated lens in front of the tweeter and midrange drivers increase and smooth output without coloring the sound, while also protecting the drivers from getting damaged.
Patented Active Ridge Technology (ART™) Surrounds
Premier features Paradigm’s patented Active Ridge Technology (ART) surrounds, made in-house and overmolded directly onto each woofer and midrange cone. This design achieves greater excursion, for a 3dB gain in output and 50% reduction in distortion. Crafted from injection-molded thermoplastic elastomer, ART surrounds are more durable and more reliable, ensuring a lifetime of superior sound.
SPECIFICATIONS
DESIGN
4-driver, 3-way bass reflex, floorstanding
CROSSOVER
2nd-order electro-acoustic at 2.5 kHz (tweeter/mid) and 800Hz (mid/woofers)
HIGH FREQUENCY DRIVER
1” (25mm) X-PAL™ dome, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
FREQUENCY RESPONSE ON-AXIS
±3dB from 45 Hz – 25 kHz
FREQUENCY RESPONSE 30° OFF-AXIS
±3dB from 45 Hz – 20 kHz
MIDRANGE FREQUENCY DRIVER
5-1/2” (140mm) Surround with Carbon-Infused polypropylene cone. Perforated Phase-Aligning (PPA™) Lens
LOW FREQUENCY DRIVER
Two 5-1/2” (140mm) ART™ Surround Carbon-Infused polypropylene cones
SENSITIVITY ROOM / ANECHOIC
91 dB / 88 dB
LOW FREQUENCY EXTENSION
33 Hz (DIN)
SUITABLE AMPLIFIER POWER RANGE
15 – 180 watts
MAXIMUM INPUT POWER
130 watts
IMPEDANCE
Compatible with 8 ohms
FINISHES
Gloss Black, Gloss White, Espresso Grain MK 2
DIMENSIONS HXWXD
39.875″ × 8.375 × 12.625″ (101.2cm × 21.2 × 32.1cm)
WEIGHT
48.2 lbs. (21.88 kg)
