Description
Superior Mineral-filled Polypropylene Bass/ Midrange Cones:
Oversized computer optimized ferrite magnets and high-power motor structures deliver detailed midrange performance with clean, extended bass.
Easy-access binding posts:
High-quality binding posts feature a larger wire access hole and connect via banana plug, pin or bare wire.
Magnetically attached grilles: neodymium magnets hold grilles firmly in place.
Bezel-Free, Micro-Perf Grilles allow you to mix and match CI Home, CI Pro and CI Elite Series for a seamless aesthetic from room-to-room!
Specifications
DESIGN
3-driver, 2-way in-ceiling, Dual-Directional Soundfield™, ABS chassis & mounting clamps
CROSSOVER
2nd-order electro- acoustic at 3.0 kHz
FREQUENCY RESPONSE ON-AXIS
±2 dB from 70 Hz – 20 kHz
HIGH FREQUENCY DRIVER
Two 3/4” (1.9cm) Exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens
MID/BASS FREQUENCY DRIVER
6.5” (16.5cm) Mineral-filled Polypropylene Cone
LOW FREQUENCY EXTENSION
52 Hz
SENSITIVITY ROOM / ANECHOIC
89 dB / 85 dB
FREQUENCY RESPONSE 30° OFF-AXIS
±2 dB from 70 Hz – 15 kHz
SUITABLE AMPLIFIER POWER RANGE
15-80 W Mono / 15-40 W Stereo
MAXIMUM INPUT POWER
100 W Mono / 50 W Stereo
IMPEDANCE
Compatible with 8 ohms
WEIGHT
1.8 kg
FINISHES
White, paintable grille, black speaker
ACCESSORIES (INCLUDED)
PB-8RN
CUT-OUT DIMENSIONS
19.6cm dia.
MINIMUM MOUNTING DEPTH
(DEPTH REQUIRED IS THE DISTANCE BETWEEN 1/2″ DRYWALL, OR SIMILAR MATERIAL.)
7.6cm
DIMENSIONS HXWXD (INCLUDES GRILLE).
8-3/4” (diameter) x 3-5/8” (depth) (22.1cm x 9.2cm)
