Description
NAD’s reference Audio Video Receiver (AVR) is a cutting-edge powerhouse for state of the art music and home theater. Well known for our high value/ high performance reputation in the AVR category, the brand’s reference model builds on that legacy with an expansion of unwavering philosophy of real-world performance, simplicity of operation, and future upgradeability.
Specifications
8 Ohms
140W (21.5dBW)
4 Ohms
170W (22.3dBW)
Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion)
9 x 85W
IHF Dynamic Power
8 Ohms
165W (22.2dBW)
4 Ohms
280W (24.5dBW)
Total harmonic distortion at rated power
<0.08%
IM distortion at 1/3 rated power
<0.03%
Damping factor
>300 (20Hz-1kHz, 8 ohms)
Input sensitivity and impedance
1.12Vrms (ref. 8 Ohms, VOL at 0dB)
Frequency response
+0.3/-0.8dB (ref. 1kHz, 20Hz-20kHz)
Signal/noise ratio
>100dB (ref. rated power at 8 Ohms, A-Weighted)
Signal/noise ratio
>85dB (ref. 1W at 8 Ohms, A-Weighted)
