Description
The Monitor Audio Silver 500 8G is formidable in both size and sonic presence, delivering commanding bass extension through twin 8-inch C-CAM drivers with RST III cone geometry.
The larger floorstanders in the Silver 8G range feature a dedicated 3-inch midrange driver and a 25 mm C-CAM Gold Dome tweeter, ensuring seamless, articulate performance across the full frequency spectrum.
Features at a glance:
2 x 8-inch C-CAM Bass Driver | 1 x 3-inch C-CAM Mid-Driver | 1 x 25mm C-CAM Gold Dome Tweeter | RST III Driver Geometry | Refined Crossover Design | Through-bolt Driver Bracing | Silent Flow Port Technology | New Outriggers | Finishes in Satin White, High Gloss Black & European Walnut.
The Most Capable Silver Series Ever
Commanding in both scale and sonic performance, the Silver 500 8G is the largest floorstander in the eighth generation Silver Series. Its twin 8-inch C-CAM bass drivers, featuring advanced RST III cone geometry, deliver deep, powerful and controlled low frequencies with exceptional clarity.
A dedicated 3-inch C-CAM midrange driver ensures natural, highly detailed vocals and instruments, while the 25mm C-CAM Gold Dome tweeter brings refined, open high frequencies with effortless precision. Together, this 3-way configuration achieves seamless, full-spectrum performance.
Optimised For Total Performance
The new high-frequency C-CAM Gold Dome tweeter has been comprehensively optimised with a vented design and internal enclosure geometry to reduce distortion and improve airflow, and an updated compression ring geometry and new ring neodymium magnet for increased magnetic efficiency. With the use of the latest UD Waveguide II, the Silver Series drivers deliver a more stable, consistent performance across all listening levels.
Transparency and Control
The RST III driver and motor system have been carefully re-engineered to deliver greater transparency and control through the critical vocal range, whilst the updated cone geometry increases rigidity and reduces colouration. A newly developed progressive spider, an upgraded voice coil and improved venting system ensure enhanced linearity, airflow and power handling.
Improved Definition
Featuring the new Silent Flow Port Technology, Silver Series 8G takes bass performance to the next level. By increasing the port diameter, turbulence is reduced significantly compared to previous ranges. The new port design also features an innovative flare geometry, inspired by the interlocking wing feathers of an owl, which guides airflow smoothly through the port and minimises chuffing for cleaner, deeper bass.
Crossover Design – Natural, Unprocessed Sound
The crossover design for Silver Series 8G has been upgraded from the previous range, with high-quality components, for more precise signal division and minimal colouration. Carefully selected capacitors, inductors and resistors improve electrical performance and reduce losses. The result? Tighter integration between drivers, enhanced clarity across the frequency spectrum, and a more coherent, natural soundstage.
Through-Bolt Technology
Through-Bolt Driver technology ensures the Silver 8G C-CAM drive units are securely braced to the rear of the cabinet and tightened to a specific torque, with the drivers and cabinets remaining structurally strong and removing any unwanted chassis resonances and strengthening the overall cabinet rigidity.
Rigid Cabinet Design
Throughout all the Silver Series 8G models, rigid internal bracing and damping are utilised to reduce resonance and panel vibration, improving transient response and overall sonic accuracy.
SPECIFICATIONS
System Format
3-Way
Frequency Response, In-Room (-6dB)
28 Hz – 35 kHz
Sensitivity (2.83 Vrms @ 1m, Free-Field)
90 dB
Sensitivity (2.83 Vrms @ 1m, Installed)
N/A
Nominal Impedance
8 Ohms
Minimum Impedance (20Hz to 20kHz)
3.6 Ohms @ 2 kHz
Maximum Peak SPL (AES75, Z-weighted)
119 dB
Continuous Power Handling (CTA 426-B)
250 W
Recommended Amplifier Power (RMS, Music Signal)
125 – 500 W into 4 Ohms
60 – 250 W into 8 Ohms
Bass Alignment
Silent Flow Port Technology
Port Tuning Frequency
33 Hz
Crossover Frequency
LF/MF: 640 Hz
MF/HF: 2.8 kHz
Drive Unit Complement
2 x 8″ C-CAM RST III bass driver
1 x 3″ C-CAM RST III mid-range driver
1 x 25 mm C-CAM Gold Dome tweeter
Finishes
High Gloss Black
European Walnut
Satin White
External Dimensions with all accessories fitted (H x W x D)
1120 x 340 x 432 mm (441/8 x 133/8 x 17″)
Weight (each)
24.3 kg (53 lb 9 oz)
Sold As
Pair
