Description
7-1/2″ mineral-filled polypropylene bass driver & 1″ titanium dome tweeter ensure great performance, while fully sealed, mineral-filled reinforced enclosures provide protection from harsh weather elements. All models have water & UV-resistant aluminum grilles, stainless steel & polymer mounting brackets, brass hardware, and gold-plated binding posts for superior toughness.
Affordable High-Performance Solutions
The Installer Series™ by MartinLogan is a line of affordable high-performance products, featuring custom installation solutions for in-wall, in-ceiling, and outdoor applications. Manufactured to the highest standards of quality, these products are available through authorized specialty custom installation specialists and carry the full MartinLogan warranty.
Specifications
Frequency Response
75–20,000 Hz ±2dB
Aiming
Swivels on U-Bracket
Recommended Amplifier Power
20—160 watts per channel
Sensitivity
93 dB
Impedance
8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Crossover Frequency
2300 Hz
High Frequency Transducer
1″ (2.5cm) titanium dome
Low Frequency Transducer
7.5” (19cm) mineral- filled polypropylene cone
Inputs
5-way binding posts accommodate wire up to 5AWG
Weight
4.8 kg
Dimensions
31.7cm x 22.4cm x 23.2cm
